M 14
The Magma 14 is a multi-function compact loudspeaker for mobile and fixed installation
applications, especially where high SPLis needed. Can be used as Main PA Systems, Monitor System, Delay and Stage fill.
Description and Technical Data
Description
Take a spin
Technical Drawing
| Feature | Details |
|---|---|
| Type | COMPACT MULTIFUNCTION SYSTEM 2 WAYS 14″ 800W AES |
| Frequency Response -10db | 55Hz – 22kHz |
| Nominal Impedance | 8 Ohm |
| Nominal Power Handling | 800 W |
| Peak | 2000 W |
| Maximum SPL output calculated | (132 db SPL) |
| Nominal Dispersion | 80°x60° (HxV) |
| Net Weight | 26.5 kg |
| Dimensions mm (±1 mm) (H x W x D) |
680 x 420 x 380mm |
